| IPC322SR3-DVSPF28-B |
IPC322SR3-DVSPF40-B |
| Camera |
| Sensor |
1/2.9″, 2 megapixel, progressive scan CMOS |
| Lens |
2.8 mm@F2.2 |
4.0 mm@F2.2 |
| Angle of View (H) |
105.2° |
76.6° |
| Shutter |
Auto/Manual, 1/6~1/100000 s |
| Min. Illumination |
Colour: 0.2 Lux (F2.2, AGC ON)
0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>52dB |
| WDR |
Optical WDR(up to 120dB) |
| Noise Reduction |
2D/3D |
| Video |
| Max. Resolution |
1920 × 1080 |
| Video Compression |
H.265, H.264,MJPEG |
| Frame Rate |
1080P (1920*1080): Max. 30 fps; 720P (1280*720): Max. 30 fps; D1 (720×576): Max. 30 fps |
| Video Streaming |
Triple |
| 9:16 Corridor Mode |
Supported |
| ROI |
Supported |
| Evaluative Metering |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 8 areas |
| Smart |
| Behavior Detection |
Intrusion, crossing line, motion detection |
| Intelligent Identification |
Face detection, Defocus, Scene Change |
| Statistical Analysis |
People counting |
| Storage |
| Edge Storage |
Micro SD, up to 128 GB |
| Network |
| Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x |
| Compatible Integration |
ONVIF,API |
| Interface |
| Network |
10M/100M Base-TX Ethernet |
| General |
| Power |
12 V DC, or PoE (IEEE802.3 af) |
| Power consumption: Max 5.5W |
| Dimensions (Ø x H) |
Φ108.5 x 81 mm (Ø4.28” x 3.2”) |
| Weight |
0.45 kg (0.99 lb) |
| Working Environment |
-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
| Ingress Protection |
IP67 |
| Vandal Resistant |
IK10 |
